5 Top, Trinocular, Stereo, Compound Microscopes (40X to 2000X)) with Camera adaptors for home and laboratory use

Like it or not, homeworking is here to stay to a greater or lesser extent. Whether you are clinicians, school or university science students, or enthusiastic hobbyists if you want to serious microscopy while working from home, then you’ll need a decent microscope with industrial/science laboratory level capabilities. Here’s 5 Top, Trinocular, Stereo Compound, Microscopes (40X to 2500X)) with Camera adaptors for home/scientific use:

1. AmScope T490B 40X-2000X Full-Size Professional Trinocular Lab Biological Compound Microscope with 3D Two-Layer Mechanical Stage

Retailing at about £340 at most outlets this OMAX Trinocular LED Lab Biological Microscope averages 4.5 out of 5 star ratings from over 140 reviews. Key features and specifications include:

Three unique features: 1) Simultaneously views sharp clear images through the trinocular port and eyepieces; 2) Has both 23mm photo port and C-mount; 3) The Length of the trinocular port is adjustable
Professional widefield optical system offers eight magnification settings 40X-80X-100X-200X-400X-800X-1000X-2000X
Heavy-duty graduated 3D two-layer mechanical stage with coaxial coarse & fine focusing, rack & pinion adjusting Abbe condenser and iris diaphragm
High quality intensity-variable halogen illumination system provides full spectrum light, giving the most colorful microscopy images
Trinocular port uses the third port for camera capabilities, or a third party to view as well, giving you the remaining two ports to view your specimen

Click to view or buy OMAX Trinocular LED Lab Biological Microscope now.

2.Swift SW380T 40X-2500X,Trinocular Compound Microscope, Siedentopf Head,Wide-Field 10X,25X Eyepieces, LED Illumination, Abbe Condenser, Double-Layer Mechanical Stage.

Retailing at about £280 at most outlets this Swift SW380T 40X-2500X,Trinocular Compound Microscope averages 4.5 out of 5 star ratings from over 78 reviews. Key features and specifications include:

Multi-purpose compound microscope for viewing tiny details of specimen slides; excellent for clinicians, school and university science students, and enthusiastic hobbyists alike
Professional Siedentopf head is fully rotatable for shared use and equipped with interchangeable wide-field 10X and 25X glass eyepieces fixed at an ergonomic 30 degree tilt to reduce neck strain, easily adjustable for different interpupillary distances without losing focus
4 DIN Achromatic objectives mounted in a revolving turret offer 6 magnification levels: 40X, 100X, 250X, 400X, 1000X, and 2500X
Ultra-precise focusing system to make coarse and extremely fine adjustments
Trinocular head accepts camera attachments (not included) in order to livestream, record, and capture magnified specimen images

Click to view or buy Swift SW380T 40X-2500X,Trinocular Compound Microscope

3.AmScope T490B-DK 40X-2000X Trinocular Compound Darkfield Microscope.

Retailing at about £400 at most outlets this AmScope T490B-DK 40X-2000X ,Trinocular Compound Darkfield Microscope averages 4.5 out of 5 star ratings from over 50 reviews. Key features and specifications include:

Four remarkable darkfield & brightfield features:
simultaneous viewing through the photo port and eyepieces
adjustable parfocal trinocular port
detachable C-Mount located on the 23mm photo port
sixteen darkfield and brightfield magnification powers

Click to view or buy Swift SW380T 40X-2500X,Trinocular Compound Microscope

OMAX – M837ZL-C180U3 40X-2500X USB 3.0 Super Speed 18MP Digital Compound Trinocular LED Lab Biological Microscope.

Retailing at about £740 at most outlets, this OMAX Trinocular LED Lab Biological Microscope averages 5 out of 5 star ratings from around over 10 reviews. Key features and specifications include:

Total magnification: 40X-100X-250X-400X-1000X-2500X; Eyepieces: wide field WF10X/18 and WF25X; Objectives: achromatic DIN 4X, 10X, 40X (S), 100X (S, Oil); Viewing head: 45 degrees inclined 360 degrees swiveling trinocular; Interpupillary distance: sliding adjustable 2-3/16inch ~ 2-15/16inch (55mm ~ 75mm); Diopter: adjustable on both eyepiece tubes; Nosepiece: revolving quadruple
Stage: mechanical stain-resistant double layer, size: 5-1/2inch x 5-1/2inch (140mm x 140mm), translation range: 3inch x 2inch (75mm x 50mm); Photo tube adjustment range: 5/8inch (15mm); Focus: coaxial coarse and fine focus knobs on both sides, rack and pinion adjustment, with tension control; Focusing knob can be locked for observation and transportation; Condenser and diaphragm: Abbe NA1.25 rack and pinion adjustment condenser with iris aperture diaphragm
Black palm rest on the base; Illumination: transmitted (lower), replaceable 3W LED light, variable intensity; Metal mechanical components; Power supply: 100V~240V 50/60Hz worldwide range (US and Canada power plug)
Digital camera: – true color 4912×3684 pixels (18M pixels) – Super speed USB 3.0 connection – 0.5X reduction lens to get larger field of view – 0.01 mm calibration slide: 1mm/100 division – Frame speed: 5.6fps at 4912×3684, 18.1fps at 2456×1842, 32.2fps at 1228×922 – Software compatible with Windows, Mac OS X and Linux operating systems – Capturing microscope images, recording live video, measuring lengths, angles, areas, editing images – USB3 cable included.

Click to view or buy OMAX Trinocular LED Lab Biological Microscope now.

5.OMAX 40X-2500X Super Speed 18MP USB3 Phase Contrast Trinocular LED Microscope with Turret Phase Disk.

Retailing at about £1,500 at most outlets this OMAX 40X-2500X Super Speed 18MP USB3 Phase Contrast Trinocular LED Microscope with Turret Phase Disk averages 4 out of 5 star ratings on Amazon. Key features and specifications include:

Total magnification for brightfield: 40X-100X-250X-400X-1000X-2500X; Total magnification for phase contrast: 100X-200X-250X-400X-500X-1000X-2500X; Eyepieces: widefield WF10X/18 and WF25X; Brightfield objectives: achromatic DIN 4X, 10X, 40X (S), 100X (S, Oil); Phase contrast objectives (in phase contrast kit): PH10X, PH20X, PH40X (S), PH100X (S, Oil); Viewing head: 45 degrees inclined 360 degrees swiveling trinocular
Interpupillary distance: sliding adjustable 2-3/16inch ~ 2-15/16inch (55mm ~ 75mm); Diopter: adjustable on both eyepiece tubes; Nosepiece: revolving quadruple; Stage: mechanical stain-resistant double layer, size: 5-1/2inch x 5-1/2inch (140mm x 140mm), translation range: 3inch x 2inch (75mm x 50mm); Photo tube adjustment range: 5/8inch (15mm); Focus: coaxial coarse and fine focus knobs on both sides, rack and pinion adjustment, with tension control
Focusing knob can be locked for observation and transportation; Condenser and diaphragm: Abbe NA1.25 rack and pinion adjustment condenser with iris aperture diaphragm; Phase contrast kit: – Substage phase contrast condenser disk with five switchable positions: – One bright field NA1.25 with iris diaphragm Abbe condenser – Four phase contrast condensers: 10X, 20X, 40X, 100X – Each phase contrast condenser can be centered individually
Four PH objectives: 10X, 20X, 40X (S), 100X (S, Oil) – 37mm mounting size in diameter – Centering telescope: 23.2mm; Black palm rest on the base; Illumination: transmitted (lower), replaceable 3W LED light, variable intensity; Metal mechanical components; Power supply: 100V~240V 50/60Hz worldwide range (US and Canada power plug)
Digital camera: – true color 4912×3684 pixels (18M pixels) – Super speed USB 3.0 connection – 0.5X reduction lens to get larger field of view – 0.01 mm calibration slide: 1mm/100 division – Frame speed: 5.6fps at 4912×3684, 18.1fps at 2456×1842, 32.2fps at 1228×922 – Software compatible with Windows, Mac OS X and Linux operating systems – Capturing microscope images, recording live video, measuring lengths, angles, areas, editing images – USB3 cable included

Click to view or buy OMAX 40X-2500X Super Speed 18MP USB3 Microscope now.
